Matsutec Ais Ha-102 Корабль Ais Трансивер Класс B Инструмент Морская Инструментация
Price section
dan boshlab
7 758 399 so'm
Технические характеристики
HA-102
Kafolatlangan yetkazib berish muddati
Agar biz 45 kun kechiksak, buyurtmani bepul olasiz. Batafsil
Har doim siz bilan aloqada
Biz har kuni savollarga har qanday savollarga javob beramiz.
To'lovni qulay usulda xavfsiz qiling
Biz to'lovlarni turli xil usullarda qabul qilamiz.
Bo'lib to'lash mavjud
Mahsulot haqida
Xususiyatlar
- Происхождение
Китай
- Напряжение источника питания
12-36
- Номер товара
HA-102
- Бренд
Matsutec
- модель
HA-102
- Цель
Трансивер, отправка трансивера AIS
- Импортировано ли оно?
Нет
- Обработка и настройка
Нет
- Номер заказа
HA-102
Tavsif
Matsutec Class B AIS Transponder
Model: HA-102
FEATURES
-
Electrical function is accordance with IEC 62297-1
-
Dual Channel function: Two TDMA receivers ar receiving datum in two independent channels at the same time, and one TDMA transmitter is transmitting in two independent channels alternately.
-
CSTDMA function can avoid and solve communication conflict.
-
Transponder has external serial data interface(RS-422, RS-232).
-
Transmit and reciever safety message, and equipped with "SOS" safety button.
-
Support three operation mode: Carrier-sense mode, assigned mode and polled mode.
-
Internal GPS reciever, as data source for position, COG and SOG can be connected to all devices compatible to GPS and PC, PDA, ECDIS, RADAR, etc.
-
Alarm and indication (via LED) for power , error, time-out, status.
Specifications
|
STANDARDS |
IEC 62297-1 |
|
|
IEC 61162-1 |
|
|
IEC 60945-2002 |
VHF RECEIVER
|
Frequency Range |
156.025MHZ ~ 162.025 MHZ |
|
Channel Bandwidth |
25 KHZ |
|
Number of AIS Receivers |
2 Receiver ( one time shared between |
|
|
AIS/DSC ) / 1 Transmitter |
|
CH-1 |
Default CH 87B ( 161.975 MHZ ) |
|
CH-2 |
Default CH 88B ( 162.025 MHZ ) |
|
Number of DSC Receiver |
1 ( CH 70) |
|
RX DSC |
156.525 MHZ |
|
Max. Usable Sensitivity |
PER less 20% at -107dBm |
VHF TRANSMITTER
|
Power Output |
2 Watt ( 33 dBm ±1.5dB ) |
|
Modulation |
GMSK / FM |
|
Data Rate |
9.6K dps / per channel |
|
Modulation Spectrum |
IEC 62287 |
DSC RECEIVER
|
Modulation |
1300 HZ / 2100 Hz FSK |
|
Data Rate |
1200 bps ± 30 ppm |
|
Spurious Response Rejection |
Over 70dB for Signal @ -104dBm; BER less 1% |
|
Blocking |
More 84dB for Signal @ -104dBm; BER less 1% |
GPS RECEIVER
|
Receiving Channels |
12 Channels |
|
Acquisition Sensitivity |
-140dBm |
|
Tracking Sensitivity |
-150 dBm |
|
Position Accuracy |
< 2.5m CEP ( GPS ) without SA |
|
Output Rate |
1 Hz |
POWER SUPPLY
|
Supply Voltage |
12V DC ( 10V ~ 20V ) |
|
Power Consumption |
Less than 10W |
MAIN UNIT
|
4 LED Indicator Working Status |
|
1 ON/OFF Switcher |
INTERFACE
|
Ports |
NMEA 0183 / RS-422 / RS-232 |
|
GPS Antenna ( Optional ) |
Female TNC Connector |
|
VHF Antenna ( Optional ) |
Female Type M Connector |
|
|
( Type N Connector optional ) |
ENVIROMENT
|
Operating Temperature |
Antenna : -25 ~ 70 C Celcius |
|
|
Others : -15 ~ 55 C Celcius |
|
Storage Temperature |
-25 ~ 70 C Celcius |
|
Humidity |
Operating: 0 ~ 95 RH at 40 C Celcius |
|
|
GPS Antenna operating : 100% Hermetically sealed |
|
|
VHF Antenna operating : 100% Hermetically sealed |
|
Vibration |
IEC 60945 |
|
Waterproof |
IPX5 |
PHYSICAL
|
Size in mm ( W ) |
234mm |
|
Size in mm ( H ) |
40mm |
|
Size in mm ( D ) |
167mm |
|
Weight |
|
Matsutec生产各种高科技产品，包括雷达、GPS和其他导航设备；鱼群探测仪、声纳及其他捕鱼设备;卫星通信系统、GMDSS和无线通信设备; 以及海底地形探测声纳，潮流测量系统和其他海洋研究设备。自成立以来，Matsutec致力于将先进的科学技术运用到捕捞作业中，并且使海上航行更安全，更经济。此外，我们还满足包括公共部门活动项目的需求，如海底勘探和资源研究。
